Soudotec T536 Aluminum Bronze Manganese TIG Rod



Special formula aluminum-bronze alloy electrode containing manganese and nickel for building up and welding copper alloys and a wide range of ferrous metals (steels, cast irons, stainless steels) to copper alloys

Typical Applications

Ideal for dissimilar assemblies, aluminum-bronze with high manganese content. Boat propellers, turbines, pumps, couplings, gear teeth, punches, dies, rolls, etc.

• Excellent for parts subjected to compressive stress and wear
• Excellent for welding a wide variety of copper alloys
• Excellent weldability out of position
• Very good corrosion resistance
• Very low friction coefficient
• Stable arc and low spatter

• Instructions for use:

  Remove any trace of oil, grease and dirt from the surface. Gouge the base metal over 3 16’’ (5 mm) thick. Preheat the copper and copper alloys between 400 – 600 ºC (752 -1112 ºF), as applicable. Maintain a short arc with a slight weaving motion. Cool before removing slag between passes.

  Available Sizes:

  • 3 32 (2.5 mm) – 1kg Package – T536.25K

  • Product Data Sheet
