Lincoln Electric 20 Plasma Cutter



The Lincoln Electric 20 plasma cutter is a professional grade, lightweight, portable plasma cutting system that can be carried anywhere with little effort. It is ideal for the farm, HVAC, autobody shop, contractor, sheet metal fabricator, and homeowner for metal cutting jobs.

Features

• Inverter design makes the 21 lbs. unit very portable and ideal for HVAC and autobody work.
• Operates on 115V, 20 amp for max. output, 115V, 15 amp for 10-15 amp output.
• For cutting expanded metal, stainless steel and aluminum.
• Built-in top mounted air pressure regulator.
• Saddle hooks for convenient cable storage.

• Technical Specifications

  Input Power		120VAC, 60Hz, Single Phase
  Output Power (Breaker Size)		20A Breaker: 20A  15A Breaker: 10-15A
  Duty Cycle (Breaker Size)		50% (15A) 40% (20A)
  Compressed Air Consumption		65PSI @ 3.5 CFM
  Torch & Leads		Integrated 9.5 torch & 8 ground lead



  What s Included

  • LE20 Plasma Cutting Power Source
  • Integrated 9.5 torch
  • Integrated 8 ground lead
  • Input power cable with 15A plug (5-15P)
  • 1 Year Warranty on Power Source, 90 Day Warranty on Torch

  • Product Data Sheet | Consumables

    Non Stock Item – Allow 1 week lead time
