ESAB OK AUTROD 308LSi Stainless Steel Wire

Stainless Steel MIG (GMAW) Wire

A continuous solid corrosion resisting chroumium-nickel wire for welding of austenitic chromium nickel alloys of 18% Cr – 8% Ni-type. OK Autrod 308LSi has a good general corrosion resistance. The alloy has a low carbon content which makes this alloy particularly recommended where there is a risk of intergranular corrosion. The higher silicon content improves the welding properties, such as wetting. The alloy is widely used in the chemical and food processing industries as well as for pipes, tubes and boilers.

Classifications		EN ISO 14343-A : G 19 9 L Si SFA AWS A5.9 : ER308LSi Werkstoffnummer : ~1.4316
Approvals		BV : 308L SA BT (M12) CE : EN 13479 CWB : ER308LSi DB : 43.039.01 DNV-GL : VL 308 L (M13) NAKS HAKC : 0.8-1.2 mm VdTÜV : 04267

Full Product Spec Sheet and Operating Ranges

Available Spool Sizes, Wire Diameter & Item Number:

• 11 lb (5 kg) – 0.030 (0.8 mm) – 1612084600
• 11 lb (5 kg) – 0.035 (0.9 mm) – 1612094600

• 33 lb (15 kg) – 0.030 (0.8 mm) – 1612089820
• 33 lb (15 kg) – 0.035 (0.9mm) – 1612099820
• 33 lb (15 kg) – 0.045 (1.2mm) – 1612119820

Spool Size	11 lb (5 kg), 33 lb (15 kg)
Wire Diameter	0.030" (0.8 mm), 0.035" (0.9 mm), 0.045" (1.2mm)
