Strong Hand Medium Duty Utility Clamps – UM F-Clamp



Utility Clamps with the Removable Reversible Clamp Arm, set-up 10x faster than a C-Clamp!

Innovative Features:

• Clamp Arm may be removed and reversed for use in spreading applications
• Tapped 5 16 -18 hole allows for attachment of V-Pads or Extender Blocks
• See 4-in-1 Kits to add versatility

•  Strong Hand UM-Series F-Clamp Specs

  • Clamping Pressure: 800 ~ 2,400 lb
  • Throat Depth: 4 ~ 7″
  • Rail Size: 25 32 x 3 8 ~ 1-3 16 x 9 16″
  • Tapped Hole: 3 8-16
  • FREE Ergonomic Comfort Handle & Cap with purchase of G & M Series clamps.

  • Part No.		Capacity – A (in)		Throat Depth -B (in)		Clamping Pressure (lb)		Rail Size – C (in)		Tapped Hole – D		Weight (lb)
    UM105		10-1 2		5-1 2		2,400		1-3 16 x 9 16		3 8-16		6.4
    UM125		12-1 2		5-1 2		2,400		1-3 16 x 9 16		3 8-16		7.0
    UM205		20-1 2		5-1 2		2,400		1-3 16 x 9 16		3 8-16		8.7

    Select Model and Capacity	UF65 – 6.5" Capacity, UM105P – 10.5" Capacity, UM125 – 12.5" Capacity, UM205 – 20.5" Capacity, UG125 – 12.5" Capacity
