BuildPro Ball Lock Bolts for 5 8 Fixture Tables

Please allow a 2 week lead time on all bolts



An essential time-saving fastener.

All Ball Lock Bolts are a time-saving and efficient method of locating and fastening fixture elements to the tabletop without having to reach underneath the table.
Insert the Ball Lock Bolt over the fixturing element and turn the knurled head with your hand for initial positioning.

The Ball Lock Bolt consists of three locking steel balls in the bolt shank that move outward to lock against the bottom chamfer of the table plate, pulling the fixture components securely downward and tightening them in place. Once all the Bolts are positioned, tighten the socket head cap screw top of the Bolts with a light turn of a hex wrench. Ball Lock Bolts release quickly from the Bolt top with a turn of your hex wrench.

Available Options and Specifications

Part No.		Type		Description		Capacity (in)		Hex Wrench Size (in)		Weight (lb)
T55010		Fixed		For connecting 2 accessories together.		0.94		1 4		0.2
T55015		Fixed		For connecting an accessory to the tabletop.		1.1		1 4		0.2
T55020		Flush		For connecting 2 accessories together.		0.94		5 32		0.1
T55025		Flush		For connecting an accessory to the tabletop.		1.1		5 32		0.1
T55050		Adjustable		Connecting tables to accessories, and accessories to accessories.		0.88 ~ 1.25		1 4		0.2
T55055		Adjustable		Connecting tables to accessories, and accessories to accessories.		0.88 ~ 1.08		1 4		0.1
T55057		Universal		Connecting tables to accessories, and accessories to accessories.		0.88 ~ 1.08		1 4		0.2

Model and Part Number	Flush Mount 0.9" – T55020, Flush Mount 1.1" – T55025, Fixed Length 0.9" – T55010, Fixed Length 1.1" – T55015, Adjustable 0.9"-1.1" – T55055, Universal – T55057
