Arcair K4000 Angle Arc Gouging Torch



Heavy Duty k4000 Gouging Torch for heavy metal removal applications such as weld preparations in pressure vessel shops and shipyards.

AMPERAGE RANGE

• 90 – 1000 amps

• ELECTRODE SIZE

  • Pointed – 5 32 – 1 2 round (4.0 mm – 12.7 mm)
  • Jointed – 5 16 – 1 2 round (7.9 mm – 12.7 mm)
  • Flat – 3 8 and 5 8 (9.5 mm – 15.9 mm)
  • Half Round – 5 8 (15.9 mm)

  • AIR REQUIREMENTS

    • psi – 80
    • kg cm² – 5.6
    • cfm – 25
    • l min – 708

    • Options

      • 7 ft. Cable – Part No. 61-082-008 (61082008)
      • 10 ft. Cable –  Part No. 61-082-009 (61082009)

      •
